FieldPilot ®
7. PrePare the Shuttle tee
Install adapters (L & R) in the shuttle tee (N) as shown. Then install adapter (Q) onto adapter (R) as
shown.
Figure 1-9: Prepare the Shuttle Tee
8. inStall the Shuttle tee & lOad SenSe hOSe
Disconnect the machine’s LS hose and install the prepared shuttle tee. Adapters (S & V) can be used as
needed to orient the shuttle tee the best for your installation. Attach original LS hose to shuttle tee and then
route and connect hose (K) from the LS port of the FieldPilot valve to the other side of the shuttle tee as
shown.
Figure 1-10: Mount the FieldPilot Valve
Q l
r
l
N
original ls Hose
K
s or V
