8
FieldPilot ®
1. PrePare the FieldPilOt ValVe
Install adapters (T) in the A, B, & T ports of the FieldPilot valve, Install adapter (U) in the P port of the
FieldPilot valve. Then install adapter (L) in the LS port of the FieldPilot valve.
Figure 1-3: Prepare the FieldPilot Valve
l
t
t
t
U
