E
NCODE
LH 500 O
PERATORS
M
ANUAL
& F
ITTING
I
NSTRUCTIONS
12
LH A
GRO
ENCODE
HA LEFT
Encode the size of the field here before start.
WORKING WIDTH
Encode the working width in centimetres.
Make sure that overlapping is accounted for. If the working width is unknown, drive
5 runs and measure the distance between the first and the last run.
Divide the measured distance by 5.
IMPLEMENT SENSOR
The signal from the implement sensor tells the monitor whether area should be
measured or not.
The time and distance counters are started and stopped with the area counter if
automatic start/stop has been selected as described on page 6.
If ISO 3-punkt is selected the implement signal is taken from the lift arms.
If PTO is selected the area counter is started when the PTO axle is turning and
stopped when the PTO axle is not turning.
FORWARD SPEED SENSOR
Selection of the forward speed sensor plus the speed calibration figure can be
encoded here.
It is also possible to automatically calibrate the forward speed sensor.
Key
Description
Pressing this key (program key 1) selects Radar as the speed
sensor (via the 7-pin DIN-ISO socket).
If the number of pulses per 100 m is known it can be encoded
directly.
Pressing this key (program key 2) selects a wheel sensor fitted on
the tractor as the speed sensor (via the 7-pin DIN-ISO socket).
If the number of pulses per 100 m is known it can be encoded
directly.
