CoMponents
Unpack the installation kit and identify the required parts for your installation.
Item Part Number Description Quantity
A 78-50203 Receiver, RX375P, SBAS ................................................................................................................................................1
B Magnet Mount Adapter, RX375P .....................................................................................................................................1
C Magnet, RX375P..............................................................................................................................................................1
D* 45-05496 Cable, RX370P DB9, Speed, Power................................................................................................................................1
D* 45-05495 Cable, RX370P Speed Only ............................................................................................................................................1
45-05338 Cable, GPS Data w/12 position Deutsch .........................................................................................................................1
D* 45-05340 Cable, Deutsch to DB9 ....................................................................................................................................................1
D* 45-05350 Cable, Com 1 & 2 with Power In ......................................................................................................................................1
* Depends on which cable was ordered with the receiver.
Item Part # Description Illustration
A 78-50203 Receiver, RX375P, SBAS
B Magnet Mount Adapter, RX375P
C Magnet, RX375P
D* 45-05496 Cable, RX370P DB9, Speed, Power
45-05496
DC: xx/xx
Speed
Out Put
19200 GGA 5 Hz
VTG 1Hz
+12v
Switched
D*
45-05495 Cable, RX370P Speed Only
Ground
Speed
45-05354
DC: xx/xx
45-05338 Cable, GPS Data w/12 position Deutsch 45-05338
DC: xx/xx
