Rx375p – TeeJet RX375P Receiver User Manual
Page 14
12
www.teejet.com
RX375P
Figure 4: Standard CenterLine System Configuration with RX375P
45
-0
53
38
78-00027
45
-0
53
24
W
ar
ni
ng
45
-0
52
98
CenterLine Lightbar
78-50111
RX375p Receiver
78-50203
Cable, GPS Data
45-05338
Cable, 2 Position
Battery
45-05298
Cable, Power
45-05324
Switchbox Ignition On/Off
78-00027 (Optional)
5 Amp
Status Detect
IGN Sense
Power In
+12 v
CL Wireless
Remote
78-50107
