Chapter 5: Local Management
5-36 2E42-27/2E42-27R/2E43-27/2E43-27R User’s Guide
5.10 SWITCH CONFIGURATION SCREEN
The Switch Configuration screen, Figure 5-17 , provides the basic setup
options to make a switch operational in your network.
To access the Switch Configuration screen from the Device Configuration
Menu screen, use the arrow keys to highlight the SWITCH
CONFIGURATION menu item and press ENTER. The Switch
Configuration screen displays up to 8 ports. To view or edit the fields for
other ports, highlight
[9-16], [17-24], or [25-27] at the bottom of the
screen and press the ENTER key.
Figure 5-17 Switch Configuration Screen
The following describes each field of the Switch Configuration screen:
Switch Address (Read-Only)
Displays the MAC address of the switch.
NOTE
The Switch Configuration screen is not available if the
operational mode of the device is set to SECURE FAST VLAN.
This screen may only be used when the device is configured to
operate as a traditional or 802.1Q switch.
Firmware Revision: XX.XX.XX
Switch Configuration
19601-18
Device Type: 2E42-27
BOOTPROM Revision: XX.XX.XX
Port #
1
2
3
4
5
6
7
8
State
learning
listening
standby
learning
listening
standby
listening
listening
2E42-27 LOCAL MANAGEMENT
Event Message Line
RETURN SAVE
MAC Address
00-00-1D-00-00-00
00-00-1D-00-00-01
00-00-1D-00-00-02
00-00-1D-00-00-03
00-00-1D-00-00-04
00-00-1D-00-00-05
00-00-1D-00-00-06
00-00-1D-00-00-07
Status
[ENABLED]
[DISABLED]
[ENABLED]
[DISABLED]
[ENABLED]
[DISABLED]
[ENABLED]
[DISABLED]
Switch Address: 00-00-1D-00-00-00
Number of Ports: 27
[9-16] EXIT
Type of STA: [DEC]
Age Time (sec): 300
