Chapter 5: Local Management
5-16 2E42-27/2E42-27R/2E43-27/2E43-27R User’s Guide
5.7 GENERAL CONFIGURATION SCREEN
The General Configuration screen, Figure 5-9 , allows the user to set the
system date and time, IP addresses and Subnet Masks, the Default
Gateway, the TFTP Gateway IP address, and the COM port configuration.
To access the General Configuration screen from the Device
Configuration Menu screen, use the arrow keys to highlight the
GENERAL CONFIGURATION menu item and press ENTER. The
General Configuration screen displays.
Figure 5-9 General Configuration Screen
The following briefly explains each General Configuration screen field:
MAC Address (Read-Only)
Displays the physical address of the 2E4X-27.
IP Address (Modifiable)
Displays and allows the user to set the IP address for the 2E4X-27. To set
the IP address, refer to
Section 5.7.1 . The IP address can also be set
through Runtime IP Address Discovery as previously described in
Section 1.4.4 .
Firmware Revision: XX.XX.XX
General Configuration
19603-15
Device Type: 2E42-27
BOOTPROM Revision: XX.XX.XX
MAC Address:
IP Address:
Subnet Mask:
Default Gateway:
TFTP Gateway IP Addr:
Device Date:
Device Time:
Screen Refresh Time:
Screen Lockout Time:
Device Uptime XX D XX H XX M
Com: [ENABLED] Application: [LM]
Clear NVRAM: [NO] IP Fragmentation: [ENABLED ]
Operational Mode: [802.1D SWITCHING]
2E42-27 LOCAL MANAGEMENT
Event Message Line
RETURN SAVE
00-00-ID-00-00-00
0.0.0.0
0.0.0.0
NONE DEFINED
0.0.0.0
01/11/97
14:23:00
03 sec.
15 min.
EXIT
