Chapter 3: Installation
3-2 2E42-27/2E42-27R/2E43-27/2E43-27R User’s Guide
3.1 UNPACKING THE 2E4X-27
1. Open the box and remove the packing material protecting the
2E4X-27.
2. Verify the contents of the carton as listed in Table 3-1 .
3. Remove the black and yellow tape seal on the non-conductive bag to
remove the 2E4X-27.
4. Perform a visual inspection of the device for any signs of physical
damage, and contact the Cabletron Systems Global Call Center if there
are any signs of damage. Refer to
Section 1.6 , Getting Help, for
details.
3.2 INSTALLING OPTIONS
If the 2E4X-27 is to be installed with an optional Fast Ethernet Interface
Module, refer to
Appendix C for installation instructions. The installation
instructions for the HSIMs are in the associated user’s guide.
Table 3-1 Contents of 2E4X-27 Carton
Item Quantity
2E4X-27 or 2E4X-27R 1
Antistatic wrist strap 1
Console Cable Kit 1
RJ21 Angle Adapter (2E43-27/2E43-27R only) 2
Rackmount Kit 1
Strain-Relief Bracket 1
Release Notes 1
Power Cord (2E42-27 or 2E43-27 only) 1
Power Cord (2E42-27R or 2E43-27R only) 2
NOTE
Install any optional equipment before proceeding to
Section 3.3 .
