Chapter 5: Local Management
5-64 2E42-27/2E42-27R/2E43-27/2E43-27R User’s Guide
3. Use the arrows keys to highlight the SAVE command at the bottom of
the screen.
4. Press ENTER. The message “SAVED OK” displays and the Time
Since Peak field is also reset.
5.19 DEVICE STATISTICS MENU SCREEN
The Device Statistics Menu screen, Figure 5-26 , provides access to
screens that allow the user to obtain switch statistics about frame traffic
through each interface and view operating statistics about each port.
To access the Device Statistics Menu from the Device Menu screen, use
the arrow keys to highlight the DEVICE STATISTICS menu item and
press ENTER. The Device Statistics Menu
screen displays.
NOTE
The following menu item on the Device Statistics Menu screen
does not display if the operational mode of the device is set to
SECURE FAST VLAN:
SWITCH STATISTICS
Section 5.7.9 provides instructions on setting the operational
mode.
