Chapter 5: Local Management
5-72 2E42-27/2E42-27R/2E43-27/2E43-27R User’s Guide
5.22 RMON STATISTICS SCREEN
RMON statistics for each interface, on an interface-by-interface basis, are
viewed through the RMON Statistics screen shown in
Figure 5-29 .
Access the RMON Statistics screen by using the arrow keys to highlight
the RMON STATISTICS field on the Device Statistics Menu screen and
pressing ENTER. The RMON Statistics screen displays.
Figure 5-29 RMON Statistics Screen
The following briefly defines each field of the RMON Statistics screen:
RMON Index (Read-only)
This field displays the current Ethernet interface for which statistics are
being shown. The 2E4X-27 has an embedded RMON agent that gathers
statistics for each of its interfaces.
Data Source (Read-only)
This field displays the source of the statistics data that is currently being
displayed on the screen.
Figure 5-29 shows that the data source for this
RMON index is Interface 1 by displaying the name IfIndex.1. If the
screen was displaying RMON statistics for Interface 4, the name
displayed would be IfIndex.4.
Firmware Revision: XX.XX.XX
RMON Statistics
1960-65
BOOTPROM Revision: XX.XX.XX
RETURN
Device Type: 2E42-27
RMON Index: X
Data Source: IfIndex.1
Drop Events:
Collisions:
Broadcast Pkts:
Multicasts:
CRC Align Errors:
Undersized Pkts:
Oversized Pkts:
Fragments:
Jabbers:
0
0
0
0
0
0
0
0
0
2E42-27 LOCAL MANAGEMENT
Event Message Line
Index: [ nn] CLEAR COUNTERS EXIT
Owner: monitor
Status: valid
Total Packets:
Total Octets:
64 Octets:
65 - 127 Octets:
128 - 255 Octets:
256 - 511 Octets:
512 - 1023 Octets:
1024 - 1518 Octets:
0
0
0
0
0
0
0
0
