Chapter 5: Local Management

5-62

2E42-27/2E42-27R/2E43-27/2E43-27R User’s Guide

To access the Broadcast Suppression screen from the Device Specific
Configuration Menu screen, use the arrow keys to highlight the
BROADCAST SUPPRESSION menu item and press ENTER. The
Broadcast Suppression screen displays.

Figure 5-25

Broadcast Suppression/Statistics Screen

The following explains each field of the Broadcast Statistics screen:

PORT # (Read-only)

Identifies the number of the port.

Total RX (Read-Only)

Displays the total number of broadcast frames received.

Peak Rate (Read-Only)

Displays the highest number of broadcast frames received in a one second
interval.

Time Since Peak (Read-Only)

Displays the time since peak rate was achieved.

Firmware Revision: XX.XX.XX

Broadcast Statistics

19601-56

Device Type: 2E42-27

BOOTPROM Revision: XX.XX.XX

PORT #

Time Since Peak

999:23:59

Peak Rate

150000

Threshold

150000

2E42-27 LOCAL MANAGEMENT

Event Message Line

Total RX

12345678910

Reset Peak

[NO]

RETURN

SAVE

[13-24]

EXIT
