744a sprayer control – TeeJet 744A Sprayer Control User Manual
Page 9
www.teejet.com
6
744A Sprayer Control
Item Part Number Description (continued)
8
32-50010
Toggle Switch
9
350-2610
Plastic Screw
10
64-50030
Foam Spacer
11
64-50025
Back Housing
12
64-50029
Elbow, Nylon (Black)
13
64-50032
Output Cable Shield, Neoprene
14
64-50026
Receptacle Fuse Shield, Neoprene
15
604-0014
Fuse, 15A
Figure 1-6: Assembly
1
8
12
15
5
8
2
3
7
6
14
13
11
6
10
8
9
4
