37
Digital Inputs and Outputs
Connectors RCA Phono (S/PDIF)
Formats S/PDIF (24 bit), EIAJ CP-340, IEC 958
Sample Rates 44.1 kHz, 48 kHz
Freq. Response DIO
DC to 22/23.9 kHz ±
0.01 dB @ 44.1/48 kHz
Analog Inputs
Connectors, balanced Mic.: XLR,
Line: 1/4" phone jack
Impedance Bal./Unbal. Mic.: 3.6/1.8 kOhm,
Line: 21/13 kOhm
Line Input Level @ 0 dBFS
+24 dBu to +0 dBu
Line Sensitivity @ 12 dB headroom
-12 dBu to +12 dBu
Mic. Input Level @ 0 dBFS Pad Off/On
-14 dBu/+6 dBu to -51 dBu/-31 dBu
Mic. Sensitivity @ 12 dB headroom Pad Off/On
-26 dBu/-6 dBu to -63 dBu/-43 dBu
Line, Mic. @ Min gain, Dynamic Range
> +92 dB, 20 Hz to 20 kHz
NF/Vi @ Max. micamp. gain, Rg = 200 Ohm
< +2 dB / -127.4 dBu
THD < -100 dB (0,001 %) @ 1 kHz
Line Frequency Response
+0/-0.1 dB, 20 Hz to 20 kHz
Mic. Frequency Response, max gain
-1.5 dB @ 40 Hz, +0/-0.1 dB (200 Hz to 20 kHz)
Crosstalk < -85 dB, 20 Hz to 20 kHz
A to D Conversion
24 bit, 128 x oversampling bitstream
A to D Delay 0.65/0.70 ms @ 48/44.1 kHz
Analog Outputs
D to A Conversion
24 bit, 128 x oversampling bitstream
D to A Delay 0.63/0.68 ms @ 48/44.1 kHz
Connectors, balanced 1/4" phone jack
Output Impedance
40 Ohm
Max. Output Level
Bal./Unbal.: +20 dBu/+14 dBu, R-load >= 1200 Ohm
Output Range
variable up to +20 dBu
Dynamic Range > +104 dB, 20 Hz to 20 kHz
THD <-98 dB (0.0013 %) @ 1 kHz
Frequency Response 20 Hz to 20 kHz, +0/-0.3 dB
Crosstalk <-100 dB, 20 Hz to 20 kHz
EMC
Complies with IEN 55103-1 and EN 55103-2 FCC
part 15, Class B, CISPR 22, Class B
Safety
Certified to IEC 65, EN 60065, UL6500 and CSA
E60065 CSA FILE #LR108093
Environment
Operating Temperature
32° F to 122° F (0° C to 50° C)
Storage Temperature
-22° F to 167° F (-30° C to 70° C)
Humidity Max. 90 % non-condensing
Control Interface
MIDI In/Out/Thru: 5 Pin DIN
Pedal 1/4" phone jack
Supplementary
Display 2x16 backlit LCD
Dimensions 19" x 1.75" x 8.2" (483 x 44 x 195 mm)
Weight 4.1 lb. (1.85 kg)
Mains Voltage
100 to 240 VAC, 50 to 60 Hz (auto-select)
Power Consumption <15 W
Warranty Parts and labor 1 year
Note: Due to continuous development and
standardization all specifications are subject to change
without notice
TECHNICAL SPECIFICATIONS
