CY7C1411JV18, CY7C1426JV18

CY7C1413JV18, CY7C1415JV18

Document Number: 001-12557 Rev. *C

Page 20 of 28

Maximum Ratings

Exceeding maximum ratings may impair the useful life of the
device. These user guidelines are not tested.

Storage Temperature ................................. –65°C to +150°C

Ambient Temperature with Power Applied.. –55°C to +125°C

Supply Voltage on V

DD

Relative to GND ........–0.5V to +2.9V

Supply Voltage on V

DDQ

Relative to GND.......–0.5V to +V

DD

DC Applied to Outputs in High-Z ........ –0.5V to V

DDQ

+ 0.3V

DC Input Voltage

[13]

.............................. –0.5V to V

DD

+ 0.3V

Current into Outputs (LOW) ........................................ 20 mA

Static Discharge Voltage (MIL-STD-883, M. 3015).. > 2001V

Latch Up Current ................................................... > 200 mA

Operating Range

Range

Ambient

Temperature (T

A

)

V

DD

[17]

V

DDQ

[17]

Commercial

0°C to +70°C

1.8 ± 0.1V

1.4V to

V

DD

Industrial

–40°C to +85°C

Electrical Characteristics

DC Electrical Characteristics

Over the Operating Range

[14]

Parameter

Description

Test Conditions

Min

Typ

Max

Unit

V

DD

Power Supply Voltage

1.7

1.8

1.9

V

V

DDQ

IO Supply Voltage

1.4

1.5

V

DD

V

V

OH

Output HIGH Voltage

Note 18

V

DDQ

/2 – 0.12

V

DDQ

/2 + 0.12

V

V

OL

Output LOW Voltage

Note 19

V

DDQ

/2 – 0.12

V

DDQ

/2 + 0.12

V

V

OH(LOW)

Output HIGH Voltage

I

OH

=

−0.1 mA, Nominal Impedance

V

DDQ

– 0.2

V

DDQ

V

V

OL(LOW)

Output LOW Voltage

I

OL

= 0.1 mA, Nominal Impedance

V

SS

0.2

V

V

IH

Input HIGH Voltage

V

REF

+ 0.1

V

DDQ

+ 0.15

V

V

IL

Input LOW Voltage

–0.15

V

REF

– 0.1

V

I

X

Input Leakage Current

GND

≤ V

I

≤ V

DDQ

−2

2

μA

I

OZ

Output Leakage Current

GND

≤ V

I

≤ V

DDQ,

Output Disabled

−2

2

μA

V

REF

Input Reference Voltage

[20]

Typical Value = 0.75V

0.68

0.75

0.95

V

I

DD

[21]

V

DD

Operating Supply

V

DD

= Max,

I

OUT

= 0 mA,

f = f

MAX

= 1/t

CYC

300 MHz

(x8)

965

mA

(x9)

970

(x18)

1010

(x36)

1130

250 MHz

(x8)

745

mA

(x9)

760

(x18)

790

(x36)

870

200 MHz

(x8)

620

mA

(x9)

620

(x18)

655

(x36)

715

Notes

17. Power up: Assumes a linear ramp from 0V to V

DD

(min) within 200 ms. During this time V

IH

< V

DD

and V

DDQ

< V

DD

.

18. Output are impedance controlled. I

OH

=

(V

DDQ

/2)/(RQ/5) for values of 175 ohms <= RQ <= 350 ohms.

19. Output are impedance controlled. I

OL

= (V

DDQ

/2)/(RQ/5) for values of 175 ohms <= RQ <= 350 ohms.

20. V

REF

(min) = 0.68V or 0.46V

DDQ

, whichever is larger, V

REF

(max) = 0.95V or 0.54V

DDQ

, whichever is smaller.

21. The operation current is calculated with 50% read cycle and 50% write cycle.
