V
ICTORY
II
VHS Models
2
NOTE: Height dimensions increase by 1
3
⁄
4
" and depth increases to 22
1
⁄
4
" when combustible floor kit is used.
Natural
#49
50
50
50
51
51
51
52 52 52
Propane
#57
58
59
59
60
60
61
62
63
63
VHS-30EP
30,000
2
8
1
⁄
8
"
14
5
⁄
8
"
190
VHS-60EP
60,000
3
11
1
⁄
8
"
17
5
⁄
8
"
250
VHS-90EP
90,000
4
14
1
⁄
8
"
20
5
⁄
8
"
310
VHS-120EP
120,000
5
17
1
⁄
8
"
23
5
⁄
8
"
365
VHS-150EP
150,000
6
20
1
⁄
8
"
26
5
⁄
8
"
425
VHS-180EP
180,000
7
23
1
⁄
8
"
29
5
⁄
8
"
485
Boiler
Model
No. of
Sections
Input
Btuh
A
B
Approx.
Total Wt.
Full of
Water (lb.)
Gas
Type
2000 3000 4000 5000 6000
7000 8000 9000 10000
Orifice
Size for
Sea Level
Orifice Sizes for High Altitudes
Includes 4% Reduction for Each 1000 Feet
Elevation — Feet
Orifice sizes indicated for sea level above are factory installed in boiler unless otherwise specified
by the local authority. Orifice table is based on a higher heating value between 1000 Btuh and
1010 Btuh for Natural Gas (See page 21, if local higher heating value exceeds these numbers).
See page 21, for burner input adjustment.
LEFT END VIEW
FRONT VIEW
RIGHT END VIEW
Figure 1. Views - Dimensions - Data
Figure 2. Base Assembly Victory II - VHS Boiler
Gas manifold
Burners
Pilot
Burner
access door
Gas valve
