VICTORY VSPH SERIES
©Slant/Fin Corp. 2007
SLANT/FIN CORPORATION, Greenvale, NY 11548 • Phone: (516) 484-2600
FAX: (516) 484-5921 • In Canada: Slant/Fin LTD/LTEE, Mississauga, Ontario
www.slantfin.com
DIMENSIONS – GAS BOILERS
®
Dimensions VSPH-60 VSPH-90 VSPH-120 VSPH-150 VSPH-180
“A” 11 1 ⁄
8
" 14 1 ⁄
8
" 17 1 ⁄
8
" 20 1 ⁄
8
" 23 1 ⁄
8
"
“B” 17 3 ⁄
8
" 20 3 ⁄
8
" 23 3 ⁄
8
" 26 3 ⁄
8
" 29 3 ⁄
8
"
12"
6"
6"
(DOTTED PIPING
BY OTHERS)
Pressure relief
valve
1 1 ⁄
2
" FPT
supply
Install manual main
shutoff valve 5' above
floor when required by
local code
3 ⁄
4
" to air eliminating
system
Dotted gas piping
by others
3" dia.
vent
connector
Press/temp
gauge
Junction
box
1 1 ⁄
2
" return tapping
1 1 ⁄
4
" cir. flange
Vent
connector
28 1 ⁄
2
"
(See note)
28 3 ⁄
4
"
(See note)
3 ⁄
4
" Drain
25 1 ⁄
8
"
(See note)
A
Jacket
B
Sediment
trap
required
30 1 ⁄
2
"
(See note)
NOTE: Height dimensions increase by 1 1 ⁄
2
" and
depth increases to 28 1 ⁄
2
" when combustible floor
kit is used.
Supply water tapping 1 1 ⁄
2
"
Circulator return flange* 1 1 ⁄
4
"
Gas tapping, natural or propane 1 ⁄
2
"
▲ AL 29-4C is a registered trademark of Allegheny Ludlum Corp.
*When not equipped with circulator, boiler 1 1 ⁄
2
" return tapping.
12"
6"
6"
12"
*2"
6"
*2"
* 6" for
enclosed
LEFT END VIEW FRONT VIEW RIGHT END VIEW
Minimum clearance
dimensions
