12

SK-2 & SK-4 Series Manual — P/N 52604:B 9/14/2010

Product Description

Controls and Indicators

Initiating Device Circuits - TB3

Alarm Zones 1 & 2 (SK-2 and SK-4)
Alarm Zones 3 & 4 (SK-4 only)
Power-limited circuitry
Operation: All zones Style B (Class B)
Normal Operating Voltage: Nominal 20 VDC, Maximum 27 VDC
Alarm Current: 15 mA minimum
Short Circuit Current: 40 mA maximum
Maximum Loop Resistance: 100 ohms
End-of-Line Resistor: 4.7K

, 1/2 watt (Part #71252)

Standby Current: 4 mA
Refer to the Silent Knight Device Compatibility Document for listed compatible devices

Notification Appliance Circuit(s) - TB2

1

One NAC on SK-2, two NACs on SK-4
Operation: Style Y (Class B)
Power-limited Circuitry
Normal Operating Voltage: Nominal 24 VDC, Maximum 27 VDC
Maximum Signaling Current: 2.5 amps total with standard transformer. 5.0 amps total (2.5 amp
maximum per NAC) with optional transformer on SK-4 only
Maximum Line Impedance: 1.5 volt drop end-of-line
End-of-Line Resistor: 4.7K

, 1/2 watt (Part #71252)

Refer to the Silent Knight Device Compatibility Document for compatible listed devices

Form-C Relays

Trouble Relay TB5 (fail-safe)
Alarm Relay TB6
Supervisory Relay TB7 (SK-4 only)
Relay Contact Ratings: 2 amps @ 30 VAC (resistive)

Resettable Special Application Power - TB1

Operating Voltage: Nominal 24 VDC
Maximum Available Current: 500 mA - appropriate for powering 4-wire smoke detectors
(see Footnote 1.)
Power-limited Circuitry
Refer to the Silent Knight Device Compatibility Document for compatible listed devices

Nonresettable Special Application Power - TB1 (SK-4 only)

Operating Voltage: Nominal 24 VDC
Maximum Available Current: 500 mA (see footnote 1 on page 12.)
Power-limited Circuitry
Refer to the Silent Knight Device Compatibility Document for compatible listed devices

1.3 Controls and Indicators

Front Panel Membrane Buttons

Acknowledge

Alarm Silence

Reset

1. Total current for resettable power and one Notification Appliance Circuit must not exceed

3.0 amps for the SK-2. Total current for nonresettable power, resettable power and two
Notification Appliance Circuits must not exceed 6.0 amps for the SK-4 (requires optional
second transformer).
