SIG SAUER BLASER R93 User Manual
Page 22
22
Safety slide down
- uncocked position
= safety on
Finger recess
Bolt handle
Warning pin of
retaining latch
Guide rail
Butt stock
Bolt stop pin
Trigger
Trigger guard
Receiver
Fore-end
Barrel
Pin notch of
scope mount
Cartridge chamber
with radial lock inner
collar
Magazine
Ejector
Extractor
Bolt head with radial lock
outer collar
Expanding shell
Opening aid
Breech lock
Safety slide up
- cocked position
= safety off
17. Operating and functional parts of the bolt assembly
R93-Manual-english 08.01.2001 16:23 Uhr Seite 22
