Crestron QM-FTCC QuickMedia™ FlipTop Computer Center
Specifications
Specifications for the QM-FTCC are listed in the following table.
QM-FTCC Specifications
SPECIFICATION DETAILS
Video
Signal Types RGB and component video 1
RGB Formats RGBHV, RGBS or RG
s
B
Video/HDTV Formats NTSC or PAL, HDTV up to 1080i/1080p 1
Gain 0 dB (75 ohms termination)
Maximum Resolution 1920 x 1200 @ 60 Hz (at unity gain) with
maximum cable length of 450 feet (137
meters) and maximum compensation at
receiver
Audio
Features Stereo audio input,
2-channel gated mic preamp
Mic Input Gain 0 to 100% (40 dB range) plus mute
Gate Level (Threshold) 0 to 100%
Attack 0 to 100 ms
Decay (Release) 0 to 5000 ms
A-D Conversion 24-bit, 48 kHz
Frequency Response 20 Hz to 20 kHz
Power Requirements
Cresnet Power Usage 8 Watts (0.33 Amp @ 24 Volts DC)
Default Net ID 1A
Minimum 2-Series Control
System Update File
2, 3
Version 3.137 (for QM-RMCRX-BA) or later
Environmental
Temperature 41° to 104° F (5° to 40° C)
Humidity 10% to 90% RH (non-condensing)
Heat Dissipation 27 BTU/Hr
Enclosure Black painted metal with black anodized or
brushed aluminum cover; flush tabletop
mountable
Dimensions (Domestic Models)
Height 5.39 in (13.69 cm) – with lid closed
Width 6.75 in (17.14 cm)
Depth 5.71 in (14.50 cm) – without mounting
brackets
Dimensions
(International Models)
Height 5.58 in (14.17 cm) – with lid closed
Width 8.50 in (21.58 cm)
Depth 6.67 in (16.95 cm) – without mounting
brackets
(Continued on following page)
Operations & Installation Guide – DOC. 6313B QuickMedia™ FlipTop Computer Center: QM-FTCC • 5
