6
4.2 Approvals
• EMC Directive 2004/108/EC
• CE compliant components
4.3 Minimum System Requirements
Electrical
Power draw
1 .2 amps @ 12 V DC
0 .6 amps @ 24 V DC
Circuit breaker/fuse
recommended size
2 amps @ 12 V DC
1 amp @ 24 V DC
Water Supply
Upper rim 0 .5 in . NPT inlet, water valve
Lower bowl jet 1 in . NPT inlet, water valve
Flow rate 15 gpm/57 lpm @ 30-50 PSI / 207-345 kPa
Discharge
Inside diameter 1 .5 in ./38 mm pipe or 1 .875 in ./47 mm hose
Horizontal run gravity drain *
Required components
Water pump ** 15 gpm/57 lpm
Potable water pressure tank ** 150 PSI working pressure rating
Electric flush switch Dometic
* Horizontal discharge plumbing must drop a minimum of 0 .125 in ./3 mm for every 1 ft ./30 .5 cm of horizontal run .
** Purchased separately . Water pump may be part of vessel’s potable water system .
Specifications subject to change without notice .
4.4 Dimensions (fig . 4
, page 2) All dimensions may vary ±3/8 inch (10 mm)
Model 9431, 9441 (with flush switch) Model 9331, 9341 (with flush handle)
Ref. Dimension
A 19 in . / 483 mm
B 14 in . / 356 mm
C 21 .5 in . / 546 mm
D 17 .5 in . / 445 mm - seat height
E 17 in . / 432 mm
F 10 .5 in . / 267 mm - centerline rough-in
G 33 .5 in . / 851 mm - seat lid up
Ref. Dimension
A 19 in . / 483 mm
B 16 .5 in . / 419 mm*
C 21 .5 in . / 546 mm
D 17 .5 in . / 445 mm - seat height
E 17 in . / 432 mm
F 10 .5 in . / 267 mm - centerline rough-in
G 33 .5 in . / 851 mm - seat lid up
* width measurement includes flush handle
Specifications SeaLand 9300-9400 Series RushFlush Toilets
