4
MODELS AND ACCESSORIES
Part Number Description
338402 TM4-2 (2VDC) TankMaster  4
3384024 TM4-24 (24VDC) TankMaster  4
3380402 TM4-2SCL (2VDC) TankMaster

4 with Seacock Monitoring Light
33804024 TM4-24SCL (24VDC) TankMaster  4 with Seacock Monitoring Light
3730200 T-2 (2 VDC) Discharge Pump
37302400 T-24 (24 VDC) Discharge Pump
600343497 Seacock Interlock Switch for Conbraco -/2" Seacock Only
600343675 Seacock Interlock Switch for Groco -/2" Seacock Only
336003 TankWatch ® 4 Panel and Cap with Vent, 22-inch Probes
336004 TankWatch ® 4 Panel and Cap without Vent, 22-inch Probes
336005 TankWatch ® 4 Panel and Cap with Vent, 45-inch Probes
336006 TankWatch ® 4 Panel and Cap without Vent, 45-inch Probes
385230272 Universal Flange (3-inch NPT) with gasket and stainless steel hardware
60034292 Plug In Relay, 2VDC
600342490 Plug In Relay, 24VDC
3853874 “Do Not Flush” Panel
33000355 Level Indicator Cap without Vent, 22-inch Probes
33000350 Level Indicator Cap with Vent, 22-inch Probes
33000346 Level Indicator Cap without Vent, 45-inch Probes
33000345 Level Indicator Cap with Vent, 45-inch Probes
SPECIfICATIONS
Product Name: TankMaster  4 Automatic Discharge Pump Controller
Electrical: 2-pin terminal block allows up to one 2-gauge wire per position.
Output Current Capability
Maximum relay rating for 2 or 24 VDC Discharge Pump: 40 amps inrush,
30 amps continuous.
Float Switch Rating: 20 watts with resistive load.
Current Consumption
“Standby” Current Draw:
2 volts DC: 0.060 amps
24 volts DC: 0.030 amps
“Pump On” Current Draw (not including pump):
2 volts DC: 0.60 amps
24 volts DC: 0.080 amps
Materials: Control Panel Housing — Polypropylene
Face Plate — Polystyrene with protective coating
Keylock Switch — Stainless steel facing
Key — Nickel-plated brass
