Dometic Tank Discharge Control Notes on using the manual
1 Notes on using the manual
Caution!
Safety Instruction: Failure to observe this instruction can cause material damage and impair
the function of the device .
Note
Supplementary information for operating the device .
fig . 1 2, page 2 : This refers to an element in an illustration . In this example, item 2 in figure
1 on page 2 .
2 General safety instructions
The manufacturer will not be held liable for claims for damage resulting from the following:
• Faulty installation or connection
• Damage to the unit from mechanical influences, misuse or abuse
• Alterations to the unit without express written permission from the manufacturer
• Use for purposes other than those described in this manual
3 Intended use
3.1 OPTION 1: DTD02 discharge control panel only
DTD02 Tank Discharge Control panel provides a key-operated switch to activate a discharge pump
that will empty a holding tank. A green light indicates when the discharge pump is operating. The
DTD02 can be used with virtually any electric discharge pump that operates on the same rated
voltage (12 V DC or 24 V DC) and a maximum circuit breaker or fuse rating of 20 amps.
Because attempting to pump-out a holding tank can be harmful if the seacock to the overboard
discharge fitting is closed, the DTD02 panel also includes a yellow warning light that indicates when
the seacock is closed. The DTD02 panel connects to two Dometic seacock switches (available
separately):
• 385310675 - seacock interlock switch and relay for Conbraco 7014701
• 385310705 - seacock interlock switch and relay for Groco BV1500
