Page 22: Economizer module

P-MAPS II, PN 271467R1, Page 21

CODE 103 - 2-Posi-

tion Damper Motor

in Options AR8 and

AR17, P/N 159892

CODE 104 - Modulat-

ing Damper Motor

with cable in Option

AR18, P/N 159877

CODE 105 - Modulat-

ing Damper Motor in

Options AR23 and

AR27, P/N 159879

CODE 112,

Damper Arm,

P/N 12635

CODE 113,

Ball and

Socket,

P/N 12636

CODE 114,

Damper Arm,

P/N 66277

CODE 110,

Potentiometer in

Option AR18,

P/N 16110 (may

be mounted on a

Remote Console)

CODE 111,

Pressure Null

Switch in

Options AR23

and AR27,

P/N 88052

CODE 116,

Damper

Arm, P/N

14225

CODE 119

- Damper

Arm, P/N

194200

Damper Linkage (see application by AR Option above):

CODE 117 - Bent Damper Rod, P/N 105420

35°

9-3/4

1/4

Bent Damper Rod

Economizer Module with Barometric Relief Hood

NOTE: Replacement parts information for these options

is incomplete. If replacement parts not listed are required,

contact your Reznor

Distributor or the factory service

department. Be prepared to provide complete Model No.,

Serial No., Option Code, and rating plate information.

Economizer Module

Economizer modules are listed by cabinet size and option code. See

page 3 for cross-reference of model/size and cabinet size.

Damper Components by Option Code (cont’d)

CODE Description

Cabinet

Size

By Option Code

AR8

AR11

AR17

AR18

AR23

AR27

AR25

114 Damper Arm, 135-0003

A,B,C

(1)

66277

115 Damper Rod, 1/4 x 33” (not illustrated) A,B,C (1)

179176

116 Pl Damper Arm Spt C-1,Cf-1

A,B,C

(1)

14225

117 Damper Rod, Bent

A,B,C

(1)

105420

118 Damper Rod 1/4” x 24” (not illustrated) A,B,C

(1)

171774

119 Crankarm Kit, J.C. #M9000-153

A,B,C

(1)

194200

120 Damper Rod 24” (not illustrated)

A,B,C

(1)

194201

CODE Description

Cabinet

Size

By Option Code

AR2E

AR2F

122

Cabinet

Adapter for RSI

Economizer

Module

(1)

208587

(1)

208589

(1)

209447

123 Outside Air

Hood

(1)

209173, RSI 63-440-03

(1)

209175, RSI 63-440-04

(1)

210122

124

Barometric

Relief Hood

with Dampers

(1)

209174, RSI 63-450-03

(1)

209176, RSI 63-450-04

(1)

210123

125 Filler Plate

(1)

209177

(1)

209178

(1)

209449

126 15-Pin Female Plug

209171, 1-480711-0

127 Modulating Damper Motor

Contact distributor; see

NOTE on left..

128 Enthalpy Control
129 Enthalpy Sensor

196290

130 Dry Bulb Sensor

217278

NOTE: Above parts are shown for replacement only. Optional

economizer modules must be ordered with the system. System

cabinet is modified to accommodate the module.

CODE 106 - Modulating Damper Motor

in Option AR25, P/N 211417
