P-MAPS II, PN 271467R1, Page 15
Open Motor Drive Table (cont’d)
Motor AK Opt
Drive Opt
AM/EM
CODE 75 - Motor
Pulley
CODE 76 - Blower
Pulley
CODE 77 - Belt
(See Note for
P/N’s.)
Serial No.
CODE (See
page 2.) HP Opt AL/EL (Voltage) (See Key, page 14.) P/N Model Bore P/N Model Bore
2 8
AK5
(208/3);
AK6
(230/3);
AK7
(460/3);
AK8
(575/3)
1, 2 110125 1VP34 7/8
111609 AK 99 1 “A-section” 3.8 ft KJ
16154 AK 104 1-3/16 “A-section” 3.8 ft DK
3, 4 106748 1VL40 7/8
111609 AK 99 1 “A-section” 3.8 ft LJ
106255 AK 94 1-3/16 “A-section” 3.8 ft EK
5, 6, 7 106748 1VL40 7/8
19111 AK 84 1 “A-section” 3.8 ft MJ
111862 AK 84 1-3/16 “A-section” 3.8 ft FK
8, 9, 10, 11, 12 106748 1VL40 7/8
18797 AK 64 1 “A-section” 3.8 ft NJ
208608 AK 64 1-3/16 “A-section” 3.8 ft GK
13, 14, 15, 16, 17
106748 1VL40
7/8
135200 AK 51 1 “A-section” 3.8 ft OJ
106758 1VL44 208610 AK 56 1-3/16 “A-section” 3.8 ft HK
18, 19, 20, 21, 22,
23, 24, 25
106758 1VL44 7/8
206125 AK44 1 “A-section” 3.8 ft WJ
194295 AK 44H 1-3/16 “A-section” 3.8 ft IK
26, 27, 28, 29
106758 1VL44
7/8
135201 AK39 1 “A-section” 3.8 ft ZJ
106748 1VL40 194296 AK 32 H 1-3/16 “A-section” 3.8 ft JK
3, 5 9, 10
AK5
(208/3);
AK6
(230/3);
AK7
(460/3);
AK8
(575/3)
9, 10, 11, 12 106748 1VL40 7/8
101414 BK130 1 “B-section” 3.8 ft UJ
208755 BK130H 1-3/16 “B-section” 3.8 ft SK
13, 14, 15, 16, 17 106748 1VL40 7/8
202654 BK105 1 “B-section” 3.8 ft VJ
208756 BK105H 1-3/16 “B-section” 3.8 ft RK
18, 19, 20, 21, 22 37451 1VM50 7/8
16153 AK104 1 “A-section” 3.8 ft AK
16154 AK104 1-3/16 “A-section” 3.8 ft UK
23, 24, 25, 26, 27,
28, 29
37451 1VM50 7/8
19111 AK84 1 “A-section” 3.8 ft BK
111862 AK84 1-3/16 “A-section” 3.8 ft VK
30, 31, 32, 33, 34,
35, 36
37451 1VM50 7/8
105483 AK69 1 “A-section” 3.8 ft CK
105484 AK71H 1-3/16 “A-section” 3.8 ft WK
7-1/2,
10
11, 12
AK5
(208/3);
AK6
(230/3);
AK7
(460/3);
AK8
(575/3)
13, 14, 15, 16 164294 1VP71 1-3/8 208756 BK105H 1-3/16 BX70 - P/N 92242 XK
17, 18, 19, 20 164294 1VP71 1-3/8 162836 BK90H 1-3/16 BX66 - P/N 92240 YK
21, 22, 23, 24 164294 1VP71 1-3/8 112026 BK75H 1-3/16 BX64 - P/N 114258 ZK
25, 26, 27, 28 164294 1VP71 1-3/8 208791 BK70H 1-3/16 BX63 - P/N 92278 AL
NOTES: Linked Belt - Assume 17 Fenner “A” or “B” belt links per foot. “A” Belt Link is P/N 201809. “B” Belt Link is P/N 202655.
If H x 1 “ bushing is required, order P/N 92203.
If H x 1 3/16” bushing is required, order P/N 106260.
Totally Enclosed (TEFC) Motor Drive Table
( NOTE: 1” blower pulley applies to Cabinets A & B; 1-3/16” blower pulley applies to Cabinet C.)
Motor AK Opt
Drive AM
Option
CODE 75 - Motor
Pulley
CODE 76 - Blower
Pulley
CODE 77 - Belt
(See Note for
P/N’s.)
Serial No.
CODE (See
page 2.)
HP Opt AL (Voltage) (See Key, page 14.) P/N Model Bore P/N Model Bore
1/2,
3/4,
1
21, 22,
23
AK5
(208/3);
AK6
(230/3);
AK7
(460/3);
AK8 (575/3)
1, 2 13580 1VL34 5/8
111609 AK 99 1 “A-section” 3.8 ft KJ
16154 AK 104 1-3/16 “A-section” 3.8 ft DK
3, 4 7962 1VL40 5/8
111609 AK 99 1 “A-section” 3.8 ft LJ
106255 AK 94 1-3/16 “A-section” 3.8 ft EK
5, 6, 7 7962 1VL40 5/8
19111 AK 84 1 “A-section” 3.8 ft MJ
111862 AK 84 1-3/16 “A-section” 3.8 ft FK
8, 9, 10, 11, 12 7962 1VL40 5/8
18797 AK 64 1 “A-section” 3.8 ft NJ
208608 AK 64 1-3/16 “A-section” 3.8 ft GK
13, 14, 15, 16, 17
7962 1VL40
5/8
135200 AK 51 1 “A-section” 3.8 ft OJ
105476 1VL44 208610 AK 56 1-3/16 “A-section” 3.8 ft HK
18, 19, 20, 21, 22,
23, 24, 25
105476 1VL44 5/8
206125 AK 44 1 “A-section” 3.8 ft WJ
194295 AK 44H 1-3/16 “A-section” 3.8 ft IK
26, 27, 28, 29
105476 1VL44
5/8
135201 AK 39 1 “A-section” 3.8 ft ZJ
7962 1VL40 194296 AK 32 H 1-3/16 “A-section” 3.8 ft JK
