Reznor RXE Parts Manuals User Manual
Page 10
Form P-X/XE/RX/RXE, P/N 264000, Page 10
Adapter Backs for Blowers and Blowers - Models XE and RXE
110
109
105
108
Drive,
page 14
Motor,
pages
11-13
Codes
100-104
107
106
110
Code 100
109
108
Motor,
pages 11-13
Drive,
page 14
Blower for
Sizes 75-225,
A10-10AC,
3/4"
Blowers for Sizes 250-300,
2A10-10A, 1"
Blowers for Sizes 350-400,
2A12-12A, 1"
Code 108 - Motor Mounting Bracket
For motors less than 1-1/2HP (for
larger motors, see Codes 113-116)
Code 112 - Replacement
Hardware for Motor
Adjustment Bracket
Assembly, Code 111
Code 111 - Motor Adjustment Bracket
Assembly for Motors less than 1-1/2HP
Codes 113 - 116
Motor Mounting
Plate for Motors
1-1/2 HP and
larger
Bolt,
P/N 16247
Bolt, P/N 16248
Nut, P/N 6554
Washer, P/N 1087
115
114
116
113
116
Code 111A,
5/16-18 x 4 lg
5/16-18
Lock
Nut
5/16-18
Hex Nut
Rubber
Grommet
5/16-18 x 3/4 lg
Square Head Bolt
P/N 44409 for
14" plate, 10"
wheel
P/N 44410 for 16"
plate, 12" wheel
Code Component Description
75, 100, 125
150, 175
200, 225
250, 300
350
400
100 Blower Adapter Back Assembly
193986
194054
194093
193988
194063
194064
101 Blower Adapter Top & Bottom
(2)
53277
--
--
--
--
--
102 Blower Adapter Sides
(2)
53278
--
--
--
--
--
103 Left Corner Support Filler
53279
--
--
--
--
--
104 Right Corner Support Filler
53280
--
--
--
--
--
Code Component Description
75, 100, 125 150, 175, 200, 225 250, 300 350, 400
105 Blower including Housing, Wheel, Shaft and Bearings
1357
1360
--
--
106 Blower with motor bracket (includes housing & wheel only)
--
--
24230
24232
107 Blower Housing and Wheel only
--
--
24229
24231
108 Blower Motor Mounting Bracket
Less than 1-1/2 HP
44409
102533
44409
102533
109 Blower Shaft
11302,
3/4 x 22
11303,
1 x 22
10120,
1 x 39-1/4
10121,
1 x 44-5/8
110 Blower Bearings
(2)
7310
(2)
10437
111 Motor Adjustment Bracket Assembly
44411
111A Hex Head Bolt 5/16 -18 x 4" for Code 226
14668
112 Hardware Bag
64940
113 Motor Mounting Plate
1-1/2 HP Motor and Larger
12578
114 Left Mounting Plate Support
12576
115 Right Mounting Plate Support
12577
116 Rod Bolt for Motor Mounting Plate Assembly
12489
117 Blower Key
19361
