Page 6
6
Unit
Model
Number
Gas
Type
Number
of
Burners
Gas
Valve
Manufacturer
2 Stage heating Operation (Btu/hr)
Orifice size for Increased Elevation
(Above sea Level)
High Fire
Low Fire
Input
Output
Input
Output
0 to
2,000 Ft
2,001 FT
to
4,000 Ft
4,001 FT
to
6,000 Ft
6,001 FT
to
7,000 FT
(*)R4G(M,N) or
R6GN-XXX*-180C
L.P.
4
White
Rodgers
153,000 122,000
100,000
80,000
49
50
51
51
(*)R4G(M,N) or
R6GN-XXX*-270C
6
230,000 184,000
149,000
119,000
49
50
51
51
(*)R4G(M,N) or
R6GN-XXX*-315C
7
268,000 214,000
174,000
139,000
49
50
51
51
NOTE: Refer to Instructions for High Altitude Deration to determine heat-exchanger capacity at increased elevations.
Table 2. Orifice or Drill Size for Propane (LP) Gases
Unit
Model
Number
Gas
Type
Heating
Input
(High Fire)
Heating
Output
(High Fire)
Heating
Rise
Range (°F)
CFM / Rise Range (1) - High Fire Data
(*)R4G(M,N) or
R6GN-150
(
†)
-180C
L.P.
153,000
122,000
20 - 50
4000
4300
4600
4900
5200
5600
sCFM
19
17
16
15
14
13
LF-Rise (° F)
28
26
25
23
22
20
HF-Rise (° F)
(*)R4G(M,N) or
R6GN-150
(
†)
-270C
230,000
184,000
30 - 60
4000
4300
4600
4900
5200
5600
sCFM
28
26
24
22
21
20
LF-Rise (° F)
43
40
37
35
33
30
HF-Rise (° F)
(*)R4G(M,N) or
R6GN-180
(
†)
-270C
230,000
184,000
30 - 60
4800
5000
5200
5400
5700
6000
sCFM
23
22
21
20
19
18
LF-Rise (° F)
35
34
33
32
30
28
HF-Rise (° F)
(*)R4G(M,N) or
R6GN-180
(
†)
-315C
268,000
214,000
30 - 60
4800
5000
5200
5400
5700
6000
sCFM
27
26
25
24
23
21
LF-Rise (° F)
41
40
38
37
35
33
HF-Rise (° F)
NOTE: (1) Temperature rise data is approximate and based on unit installations of 2,000 feet or less.
LF=Low Fire, HF=High Fire
Table 3. heating Rise / Range
unit model Number
Gas
Valve
Manufacturer
Gas
Valve
Model No.
maximum
Inlet
Pressure
(
†)
minimum
Inlet
Pressure
(
†)
Factory set
Manifold
Pressure
(
†)
High Fire
Factory set
Manifold
Pressure
(
†)
Low Fire
(*)R4G(M,N) or R6GN-XXX*-180C
White
Rodgers
36H64
14.0 (3.49)
11.0 (2.74)
9.5 (2.37)
5.0 (1.24)
(*)R4G(M,N) or R6GN-XXX*-270C
(*)R4G(M,N) or R6GN-XXX*-315C
NOTE:
†
Pressure values are expressed in: in-WC (kPa)
Table 4. Unit / Valve data - LP gas only
