COPYRIGHT © 2014 RED.COM, INC
RED 4K BROADCAST MODULE OPERATION GUIDE
955-0072, REV-D | 23
SUPPORTED FREQUENCIES
SUPPORTED FREQUENCIES
1
FREQUENCY (HZ)
SMPTE STANDARD
23.98, 24.00, 25.00, 29.97, 30.00
HD-SDI
SMPTE ST 292 (1.485 Gbps)
50.00, 59.94
3G-SDI
SMPTE ST 424 (2.970 Gbps)
SMPTE ST 425 (2.970 Gbps)
1. Ensure you select a frequency supported by your monitor.
ATTACH 4K BROADCAST MODUlE
You can dock the 4K Broadcast Module to the following devices:
Module Adaptor
+1 Adaptor Module
COMPATIBlE RED DEVICES
You can attach the following devices directly to the back of the 4K Broadcast Module:
Pro Battery Module (Dual)
Pro Battery Module (Quad)
Quickplate Adaptor
Quickplate Module
REDMOTE
REDVOLT XL Module
COMPATIBlE TIMECODE AND GENlOCK DEVICES
The 4K Broadcast Moduleis compatible with the same timecode generators and genlock devices as the DSMC
BRAIN. For more information about what devices are compatible with the DSMC BRAIN, see the
, available at
.
B
4K BROADCAST MODuLE
COMPATIBILITY
