PS Engineering Inc. ®
PAR200 Audio Selector Panel, COM radio Controller and Intercom System
Installation and Operator’s Manual
200-228-0000 Page 1-2 Rev. 4, Dec. 2013
1.4 APPROVAL BASIS — FAA TSO
1.1.1 PAR200
The PAR200 Intercom is FAA approved under TSO C139 (Aircraft Audio Systems and Equipment) and
contains partial elements of TSO C169a (VHF Radio Communications Transceiver Equipment Operating
Within Radio Frequency Range 117.975 To 137.000 Megahertz).
The partial TSO applies to C169a, because the PAR200 unit provides control and display only for the
TY91-series of VHF communications equipment.
The PAR200-series Audio Selector Panels are FAA approved under TSO C139 (Aircraft Audio Systems
and Equipment). The VHF Communication Transceiver portion of the PAR200 is TSO approval under
TSO C169a.
The audio system complies with relevant portions of ED-14C/DO-160G (Environmental Conditions and
Test Procedures for Airborne Equipment), DO-254, (Design Assurance Guidance for Airborne Electronic
Hardware) and ED-18/DO-214 (Audio Systems Characteristics and Minimum Operational Performance
Standards for Aircraft Audio Systems).
NOTE:
The conditions and tests for TSO approval of this article are minimum performance standards.
Those installing this article, on or in a specific type or class of aircraft, must determine that the
aircraft installation conditions are within the TSO standards. The article may be installed only
following 14 CFR Part 43 or the applicable airworthiness requirements.
1.1.2 Trig TY91-Series:
The VHF Communication Radio (Trig Avionics TY91L)is EASA and FAA-approved under ETSO
210.10042695, Rev, B or Subsequent Revision, under 2C169a Class C, E, H1, H2, 4, 6, ETSO 2C128,
TSO C169a Class C, E, 4, 6, TSO C128a TSO-C169a, ETSO 2C169a Class C, E, H1, H2, 4, 6, ETSO
2C128, TSO C169a Class C, E, 4, 6, TSO C128a EUROCAE ED-23C, EUROCAE ED-67, EUROCAE
ED-14F (RTCA DO-160F), RTCA DO-186B, RTCA DO-207 ED-12B (RTCA DO-178B) Level B DO-
254 Level C
FCC Identification VZI00882
Applicable documents EUROCAE ED-23C, EUROCAE ED-67, EUROCAE ED-14F (RTCA DO-160F),
RTCA DO-186B, RTCA Software ED-12B (RTCA DO-178B) Level B Hardware DO-254 Level C
Operation is subject to the following conditions:
This device may not cause harmful interference. This device must accept any interference received, in-
cluding interference that may cause undesired operation.
1.5 SPECIFICATIONS
Audio Selector/Intercom FAA TSO C139
Communications Transceiver FAA TSO-C169a (PARTIAL)
Environmental Qualification DO-160G A1C1BAESRXXXXXXZ B(XX)ABATTBXXA2E2 XXX
Operating Temperature Range: -20º C to 55ºC , short term -40°C to +70°C
Altitude: Up to 35,000 feet in an non-pressurized area
WEIGHT
PAR200 Unit
Rack with connectors
1.1 lb. (0..49 kg)
0.51 lb. (0.24 kg)
AUDIO PANEL POWER REQUIREMENTS (Including Internal Lighting):
Voltage: 11-33 VDC
Maximum Current: 2.5 Amp (Externally protected by a 3A pull-type
breaker)
