PAR200 Audio Selector Panel, COM radio Controller and Intercom System
Installation and Operator’s Manual
200-228-0000
Page 2-11
Rev. 4, Dec. 2013
Figure 2-4 DIP switches
Change the settings as shown in the table below.
Switch
Noisy Cockpit
Normal Cockpit
Switch Bank
Pilot Microphone
1
OFF
ON
2
ON
OFF
Copilot Microphone
3
OFF
ON
J5
4
ON
OFF
Passenger 1 Microphone
1
OFF
ON
2
ON
OFF
Passenger 2 Microphone
3
OFF
ON
J4
4
ON
OFF
Table 2-6 Microphone gain settings
Carefully reassemble the unit.
2.11 Reassembly
1. Using the nylon spacer removed in step 2, compress the spacer so it becomes ob-
long.
1
2
3
4
5
6
ON
OFF
ON
OFF
