PS Engineering Inc. ®
PAR200 Audio Selector Panel, COM radio Controller and Intercom System
Installation and Operator’s Manual
200-228-0000 Page 3-4 Rev. 4, Dec. 2013
3.6.2 Tuning 8.33 kHz channel Spacing
Push and hold the right hand knob until the volume screen appears. Then hold the
“MUTE” button on the left side until a sidetone level/channel spacing screen appears.
Turn the large knob to select either 25 kHz spacing or 8.33 kHz spacing.
3.6.2.1 Channel Assignment under 8.33 kHz spacing:
The following table provides an example of the 8.33 Channel assignments as displayed on the PAR200,
when in the 8.33 mode.
Bandwidth (kHz) Frequency Displayed
25 118.00000 118.000
8.33 118.00000 118.005
8.33 118.00833 118.010
8.33 118.01666 118.015
25 118.02500 118.025
8.33 118.02500 118.030
8.33 118.03333 118.035
8.33 118.04166 118.040
25 118.05000 118.050
8.33 118.05000 118.055
8.33 118.05833 118.060
8.33 118.06666 118.065
25 118.07500 118.075
8.33 118.07500 118.080
8.33 118.08333 118.085
8.33 118.09166 118.090
N1
1. Push/hold for >1 second.
2. After the volume screen appears up, hold
mute until SIDETONE screen appears
3. Select either 25 kHz or 8.33 kHz with
large knob/underscore cursor
