MODEL A2 (12V/24V) A4 (12V/24V)
RATING 2 kW (6,800 BTU) 4 kW (13,600 BTU)
OPERATING VOLTAGE
Stand-By 0.4 W 0.4 W
Ignition 130 W 145 W
Maximum Heat 25 W 60 W
FUEL CONSUMPTION 0.03–0.06 US gal/hr (0.1–0.22 l/hr) 0.06–0.012 US gal/hr (0.21–0.46 l/hr)
FUEL TYPE ULSD, Diesel # 1, Diesel # 2, Arctic, B5 Bio-diesel
OPERATING Ventilation mode: -40°F to 149°F (-40°C to 65°C)
TEMPERATURE
Heating Mode: -40°F to 104°F (-40°C to 40°C)
RANGE
AIR FLOW 41 CFM (70 m³/hr) 65 CFM (110 m³/hr)
WEIGHT (Maximum) 7.7 lb (3.5 kg) 11.2 lb (5.1 kg)
DIMENSIONS (L x W x H) 14 x 4.75 x 6.14 inches (355 x 120 x 156 mm) 16.4 x 6.1 x 7.4 inches (417 x 154 x 189 mm)
WARRANTY Two years parts and labor
DESCRIPTION QTY
Air Heater A2 or A4
12 or 24 V 1
Heater to Battery Harness 2
Driver Control Panel (DCP) 1
DCP to Heater Harness 1
DCP to Ignition Harness 1
Fuses 7.5 or 15A 2
Fuel Pump 12 or 24 V 1
Fuel Pump to Heater Harness 1
Fuel Pump Bracket 1
Fuel Pickup Pipe 1
DESCRIPTION QTY
Fuel Lines Rubber 4
Fuel Lines Plastic 2
Fuel Line Clamps 8
Air Intake Silencer 1
Exhaust Pipe 1
Exhaust Pipe P Clamp 1
Installation Hardware
Package 1
Hot Air Duct (optional) 1
Owner's Manual 1
1.0
PROHEAT AIR A2/A4 INSTALLATION MANUAL 1-1
TECHNICAL
SPECIFICATIONS
PACKAGE CONTENTS 1.1
Check box carefully and report any missing parts to your dealer or supplier.
