PROHEAT AIR A2/A4 INSTALLATION MANUAL 3-1
3.1
Inspect the entire installation for:
a. Loose bolts.
b. Loose hose and hose clamps.
c. Loose wire and wire connections.
d. Kinked hoses or wiring.
e. Battery connection for correct polarity.
Verify the battery power
Install both fuses at the battery box and the heater. Use 15A fuses for 12
volt systems and 7.5A fuses for 24 volt systems.
SETTING UP THE DCP
Set Time
The time symbol (00:00) appears in the lower left corner of the display, the
first two 00: flash. Using the LEFT and RIGHT buttons, set the hour. Press
the TIMER button. Set the minutes. Press the TIMER button.
3.0.1
3.0.2
3.1.1
FIRST TIME START UP 3.0
2 6
3 5
4
1
1 Status LED Light
2 Fan Button – Fan On or Off
3 Left Button
4 Timer/Enter Button
5 Right Button
6 Heat Button – Heat On or Off
Figure 27 Driver Control Panel (DCP).
