90 MBOX ® DIRECTOR USER MANUAL
APPENDIX A. REFERENCE
OSC Syntax
General:
Labels Output:
All Server 1 Layer 1 Parameters:
Path Value Range Description
/md (no value) resend feedback for all OSC parameters
/md/menu/layer1 1.0 select only layer 1
/md/menu/layer1+- 0.0 or 1.0 toggle selection of layer 1
/md/menu/server1+- 0.0 or 1.0 toggle selection of server 1
/md/selected/opacity 0.0 to 1.0 set opacity for selected layer.
/md/server1/layer1/opacity 0.0 to 1.0 set opacity for server 1, layer 1.
/md/server1/master/intensity 0.0 to 1.0 set intensity for server 1, master.
/md/menu/nextscene (no value) recall next scene in scene table
/md/scene/2.1 (no value) recall scene with name beginning with '2.1'
/md/palette/1 (no value) recall palette 1
/md/palette/1/time (no value) recall palette 1 with timing
/md/palette/1/timeonly (no value) recall palette 1 (timing only, not values)
Path Value Range Description
/md/selected/effect1/label string name of the effect 1
Path Value Range
/md/server1/layer1/effect1 0.0 to 1.0
/md/server1/layer1/effect1/dmx 0 to 255
/md/server1/layer1/fx1ctrla 0.0 to 1.0
/md/server1/layer1/fx1ctrla/dmx 0 to 255
/md/server1/layer1/fx1ctrlb 0.0 to 1.0
/md/server1/layer1/fx1ctrlb/dmx 0 to 255
/md/server1/layer1/effect2 0.0 to 1.0
/md/server1/layer1/effect2/dmx 0 to 255
/md/server1/layer1/fx2ctrla 0.0 to 1.0
/md/server1/layer1/fx2ctrla/dmx 0 to 255
/md/server1/layer1/fx2ctrlb 0.0 to 1.0
/md/server1/layer1/fx2ctrlb/dmx 0 to 255
/md/server1/layer1/opacity 0.0 to 1.0
/md/server1/layer1/opacity/dmx 0 to 255
/md/server1/layer1/red 0.0 to 1.0
/md/server1/layer1/red/dmx 0 to 255
/md/server1/layer1/green 0.0 to 1.0
