INSTALLATrON
SUPPUEDD CABLES:
m
1 X mains cable
2 X hifi connection cable (cinch)
1 X digital cable (cinch)
MAINS CONNECTION
• Before connecting the unit to the mains, proceed as
follows:
- If the unit is equipped with a VOLTAGE selector, first
adjust the voltage selector to the local mains voltage.'
- If the unit does not have a voltage selector, first
check if the mains voltage as shown on the type
plate on the back of the unit corresponds to your local
mains voltage. If it does not, consult your dealer or
sen/ice organisation.
• After all other connections have been made, connect
the mains lead to the AC MAINS socket and insert
the mains plug in the wall socket.
ANALOG CONNECTIONS
ANALOG PLAY - Connect these sockets via the
supplied hifi connection cables to the DCC INPUT
sockets of your amplifier. You can also use the TAPE 1,
TAPE 2 or AUX INPUT of your amplifier but never the
PHONO INPUT socket.
ANALOG REC - Connect these sockets via the supplied
hifi connection cables to the DCC OUTPUT sockets of
your amplifier. You can also use the TAPE 1/2 or AUX
OUTPUT sockets of your amplifier.
DIGITAL CONNECTIONS
The DCC951 can be connected to your CD player via
the digital or via the optical socket, depending on the
available outputs on your CD player.
Recordings through a digital connection guarantee
optimum recording quality; record level setting is then
not necessary.
DIGITAL IN - Connect this socket via the supplied
digital cable to the corresponding digital output socket
of e.g. CD and DAT or to the digital selector of some
Philips amplifiers.
OPTICAL IN - Pull out the protective plug from the
socket. Connect this socket via an optical lead
(SBC1150) to the corresponding optical output socket
of e.g. CD and DAT.
NOTE: when you are not using the DIG IN connections,
for the CD, the PRESETS of the DCC must be changed
by using the preset key.
iCT For this refer to the chapter 'PRESETS'.
OPTIONAL CONNECTION
DIGITAL OUT - Connect this socket via a cinch cable to
the corresponding digital input socket of e.g. an
amplifier with D/A convertor or another digital recorder.
ESI BUS .
In case your system consists of products of the Philips
900 series, the ESI BUS connections are recommend­
ed. Connect the ESI BUS socket as shown to the ESI
BUS socket of e.g. your amplifier. In this way you can
fully enjoy the ease of operation thanks to the intelli­
gent communication between the sets in your Philips
900 system . (Automatic recording source selection)
REMOTE CONTROL
Open the battery compartment and insert two
batteries, type R03, UM-4 or AAA-cells.
CD PLAYER
ANALOG
-◄ © R
DIGITAL
@ ►-
ESI BUS
b 2 a
JZ
_52
"5)
c
LU
ESI BUS
^ ©
