PRELIMINARY
CY14B104K, CY14B104M
Document #: 001-07103 Rev. *K Page 26 of 31
Package Diagrams
Figure 17. 44-Pin TSOP II (51-85087)
MAX
MIN.
DIMENSION IN MM (INCH)
11.938
(0.470)
PLANE
SEATING
PIN 1 I.D.
44
1
18.517 (0.729)
0.800 BSC
0°-5°
0.400(0.016)
0.300 (0.012)
EJECTOR PIN
R
G
O
K
E
A X
S
11.735
(0.462)
10.058
(0.396)
10.262
(0.404)
1.194
(0.047)
0.991
(0.039)
0.150
(0.0059)
0.050
(0.0020)
(0.0315)
18.313 (0.721)
10.058 (0.396)
10.262 (0.404)
0.597 (0.0235)
0.406 (0.0160)
0.210 (0.0083)
0.120 (0.0047)
BASE PLANE
0.10 (.004)
22
23
TOP VIEW BOTTOM VIEW
51-85087 *A
