OmniSistem Sky Scan - Manual (Page 7)

128>135 = Pattern8 Small
136>143 = Pattern8 Large
144>151 = Pattern9 Small
152>159 = Pattern9 Large
160>167 = PatternA Small
168>175 = PatternA Large
176>183 = PatternB Small
184>191 = PatternB Large
192>199 = PatternC Small
200>207 = PatternC Large
208>215 = PatternD Small
216>223 = PatternD Large
224>231 = PatternE Small
232>239 = PatternE Large
240>255 = Manual Mode as follows:
DMX Manual Mode:
DMX Base+0 = 240 or greater
DMX Base+1 = 0 to 255
Sweep speed 0 is slowest and 255 is fastest
DMX Base+2 = 0 to 255 Start position of a sweep, positions 1 to 13
DMX Base+3 = 0 to 255 Ending position of a sweep, positions 1 to 13
DMX Base+4 = 0 to 255 beam position enables 13,11,9,7,5,3,1 right sweep only
DMX Base+5 = 0 to 255 beam position enables 12,10,8,6,4,2 right sweep only
DMX Base+6 = 0 to 255 beam position enables 13,11,9,7,5,3,1 left sweep only
DMX Base+7 = 0 to 255 beam position enables 12,10,8,6,4,2 left sweep only
Set DMX Base+4 through Base+7 all maximum. This enables all beam positions in both directions of sweep.
Set DMX Base+2 to zero and Base+3 to maximum. This selects the full scan range.
Adjust DMX Base+1 to different values to control the pause time at each beam position.
Adjust DMX Base+4 to Base+7 to different values to enable and disable beam positions in both directions of
sweep.
To set a DMX Base address, do the following procedure:
Decide the base address desired from 1 to 503.
Write the desired number down on paper.
Addressing – Sky-Scan 6.0
