OmniSistem Sky Scan - Manual (Page 6)

Odd numbered patterns are beams only and even numbered patterns are fans only determined by sound
and then repeating several times.
This pattern requires switch #8 be set ON to view it.
Switch #7 On: (Sound Triggered)
PatternD Beam Type: A single beam that toggles between two close positions only, over the full legal limit
set by switch #9, holds at each beam position pair until a sound trigger bumps the pair to another random
position.
This one is timed for about 15 seconds before proceeding to next.
PatternE Fan Type: A small fan that targets a single fan position only, over the full legal limit set by switch
#9, holds at each fan position until a sound trigger bumps the fan to another random position.
This one is timed for about 15 seconds before proceeding to next. This pattern requires switch #8 be set ON
to view it.
See Section below for setting the Base Address.
Set switch #10 to OFF (down) to enable DMX Mode of operation.
This control allows you to use 1 channel -OR- 8 channels of DMX.
If the Base DMX channel stays below the value 240 then a single DMX channel is all that’s required. If the
Base channel exceeds the value 240 then the next 7 DMX channel addresses are used to supply values for
full manual control.
See pattern descriptions 1 through E under Full Automatic.
DMX Single Channel Operation
DMX Base Value: (the symbol '>' means through)
0>15
= Laser OFF. Scanner rests in OFF position.
16>23
= Pattern1 Small
24>31 = Pattern1 Large
32>39
= Pattern2 Small
40>47 = Pattern2 Large
48>55 = Pattern3 Small
56>63 = Pattern3 Large
64>71
= Pattern4 Small
72>79 = Pattern4 Large
80>87
= Pattern5 Small
88>95 = Pattern5 Large
96>103
= Pattern6 Small
104>111 = Pattern6 Large
112>119 = Pattern7 Small
120>127 = Pattern7 Large
DMX-512 Mode – Sky-Scan 5.0
