Oakworks 121A Procedure Chair Rev.B - Manual (Page 8)

Trendelenburg -
head end down
(up to 15º)
Reverse Trendelenburg -
foot end down
(up to 5º)
height up
height down
back
rest
up
back rest down
5
DIReCTIONS fOR USe
CAUTION
fOOT CONTROl OPeRATIONS
Do not sit on the Fowler (Backrest) or Leg Rest sections. Do not leave the patient unat-
tended. When lowering the chair or using the Trendelenburg functions, make sure there is
nothing that can impede motion (like stools, cabinets, accessory parts, cleaners, etc.)
The Multi-function Foot Control and optional Hand Control operate all functions of the chair with
the touch of a button. Follow the directions below to access these functions.
hAND CONTROl OPeRATIONS (OPTIONAl)
Trendelenburg - head
end down (up to 15º)
height up
back rest up
Trendelenburg - foot
end down (up to 15º)
height down
back rest down
