Novak Rooster Crawler Addendum (to be used with Rooster 12T instructions (56-1841-2) - Manual

#1841 ROOSTER
CRAWLER ESC
ADDENDUM
#56-1841-2 10/2007
Parameter Profile 1 Profile 2
W/ Reverse Yes Yes
% Reverse 100 100
Drag Brake 90% 90%
Li-Po Cut-Off Disabled Enabled
©2007 Novak Electronics, Inc. All Rights Reserved
www.teamnovak.com
This Addendum addresses issues specific to the #1841 Rooster
Crawler-Edition Brushed ESC and should be referred to instead of
the original instructions for the changes as noted below.
This product features high drag brake, no push brake, a 6V/5A BEC and
a 27-turn brush motor limit. The recommended motor is Novak #3555
Fifty-Five Crawler 55-Turn.
Use this product only in crawling applications where high drag brake and
no push brakes are needed. Use in other applications or in higher load
applications will void the warranty as stated in the main Rooster 12T
instruction manual included with this product.
THIS PRODUCT HAS A 27-TURN BRUSHED MOTOR LIMIT. USE WITH
LOWER TURN MOTORS WILL VOID THE WARRANTY.
ROOSTER CRAWLER THROTTLE PROFILES:
