GTB DRAG BRAKE VALUES
INSTRUCTION ADDENDUM
Refer to this addendum in place of the information in the
product’s main instruction manual for the following.
This version GTB now has Drag Brake values that have been optimized for use
with sintered magnet rotors. These updated values allow for much finer tuning
of the Drag Brake for optimum performance with our newest sintered rotors.
UPDATED DRAG BRAKE VALUES
This software adjustment is accessed with the ESC turned on, Profile 1-4 or 6
active, and ESC connected to a charged battery pack (transmitter on or off):
PRESS & HOLD the ESC’s SET button until the BLUE & AMBER
LEDs turn on solid together. Quick press & release SET button to change
the Drag Brake setting, then press & hold SET button for about 1 second to store
selection into ESC’s memory, and return to neutral.
Set ting (# of flashes) : 1 2 3 4 5 6 7 8 9 10
Drag Brake (%): off 3 6 9 12 15 18 21 24 27
NOTE: To disable Drag Braking and re-activate the standard style of braking (no drag brakes
during neutral), repeat Minimum Brake adjustment as described in main instruction manual.
w w w . t e a m n o v a k . c o m
(949) 833-8873 • FAX (949) 833-1631
Customer Service E-mail: [email protected]
Monday-Friday: 8:00am-5:00pm (PST)
