Novak GTB Li-Po Cut-Off Addendum (56-1714-1) User Manual
Gtb 4-cell instruction addendum
This Addendum should be referred to instead of the included original
instructions for the following changes which are noted below.
The GTB 4-Cell was designed for use only in lower-load applications where
only 4 cells are used such as oval and 1/12 on-road cars. Use with more
than 4 cells or in higher load applications like touring cars will void the
warranty as seen in the main GTB instruction manual included with
this product.
SPECIFICATIONS:
All specifications are identical to those found in the GTB Main Instructions
except for the following:
Input Voltage ..............................4 Cells (1.2 Volts DC/Cell)
ESC Weight (w/o wires).............1.01 ounce (29 grams)
PROPER GEAR SELECTION Starting Points:
Gearing is given in rollout for each brushless motor turn (i.e. 4.5). Rollout is
determined by dividing tire circumference (tire diameter x 3.14) by spur and
pinion gear ratio. Example: (1.75” x 3.14) ч (100 ч 23) = 1.26 rollout.
For optimum 4 cell performance, it is not recommended to exceed
temperatures of 160˚F (71˚C) on the ESC or Motor. Reduce gearing if
necessary.
Vehicle
13.5
10.5
8.5
7.5
6.5
5.5
4.5
3.5
1/10 Oval
2.75
2.50
1.70
1.60
1.50
1.40
1.30
1.20
1/12 On-Road
2.50
2.10
1.50
1.40
1.30
1.20
1.10
1.00
THROTTLE PROFILE SELECTION
The GTB 4-Cell ESC is equipped with 6 user-selectable throttle profiles as
shown below.
GTB 4-CELL THROTTLE PROFILES
BRUSHLESS PROFILES
BRUSHED
MODE
1
2
3
4
5
6
w/ Reverse
No
No
No
No
Yes
No
% Reverse
0
0
0
0
100
0
Programmable
Yes
Yes
Yes
Yes
Yes
Yes
Min Drive
1%
1%
1%
1%
2%
3%
Min Brake
10%
15%
20%
25%
30%
20%
Drag Brake
10%
15%
20%
25%
30%
off
Dead Band
4%
4%
4%
4%
4%
4%
ADVANCED—CUSTOM PROGRAMMING
Drag Brake Values. Drag brake values have been optimized for use with
sintered rotors and 4-cell applications, and allow for much finer adjustments.
Setting
(# of Flashes):
1
2
3
4
5
6
7
8
9
10
Drag Brake
(%):
off
3
6
9
12
15
18
21
24
27
