Novak 4PHD 4-Pole Brushless Motor
Replacement Parts
It is highly recommended that if you are replacing anything in
the motor, the whole motor should be disassembled, cleaned,
parts replaced, and motor reassembled.
Refer to instructions on the other side.
www.teamnovak.com
4PHD Motor Replacement Parts are available from your
local hobby dealer or can be purchased on the Novak
webstore www.teamnovak.com/shop
PRODUCT WARRANTY: Novak R/C, Inc. guarantees all products to be free from
defects in materials or workmanship for a period of 120 days from the original date
of purchase (verified by dated, itemized sales receipt). Warranty does not cover incor-
rect installation, components worn by use, damage resulting from thermal overload
or use of excessive timing, burned stators, physical damage from being dropped,
corrosion, abrasion from any foreign materials, or any damage caused by a crash,
flooding, or other natural disaster. In no case shall our liability exceed the product’s
original cost. We reserve the right to modify warranty provisions without notice.
©2014 Novak R/C, Inc. All Rights Reserved
Customer Service:
(949) 916-6044 • Mon-Thu 8am - 4pm (PST)
e-mail:
Novak 4PHD 4-Pole Brushless Motor
Replacement Parts
It is highly recommended that if you are replacing anything in
the motor, the whole motor should be disassembled, cleaned,
parts replaced, and motor reassembled.
Refer to instructions on the other side.
Rotor
(#5956)
Front Endbell &
Bearing Set
(#5958)
Timing
Assembly
(#5957)
Back Endbell &
Bearing Set
(#5959)
Screw Set
(#S5934)
Wound
Stator
with Can
& Wires
(#S6510)
Novak’s premium
quality Speed
Lube (#5860) is
recommended for
lubricating the
high-speed ball
bearings of the
4PHD Motor
NOVAK 4PHD 4-Pole Sensored Brushless Motor
(#3510)
