PARTS LISTS
The parts that come with your UC4+ Spray Height Control System are listed in Table 1. The item
number on the left side of this table references each part.
Please ensure that all parts in your kit are present before proceeding with your installation.
Table 1: JOHN DEERE 4920 Spray Height Control System Parts
Item Part Number Name Quantity
B05 44706-01 KIT CABLE TIE BLACK 10 PCS 21 IN 150 PCS 7.5 IN 1
B10 44700-06 BRACKET VALVE MOUNTING STD 1
B11 44743 MOUNTING BRACKET MAIN LIFT SENSOR UC4 PLUS 1
B15 105415 CLAMP EXHAUST 2IN PLATED 4
B16 105416 CLAMP EXHAUST 1-1/ 4 IN PLATED 4
B17 44972 SENSOR MOUNTING BRACKET LOW PROFILE RAINFLAP 16GA 2
B20 44971 SENSOR MOUNTING BRACKET LOW PROFILE 16GA 2
C01 44662B-40 CABLE UC4 SENSOR TRUNK AMPF TO AMPF BLACK STANDARD 40FEET 1
C02 44668 CABLE UC4 SENSOR BRANCH 1 AMP RECEPT 3 AMP PLUG BC 1
C02B 44664 CABLE UC4 CAN NODE DUAL 1
C03 44656D CABLE VALVE VARIABLE RATE DT 1
C04 44651 CABLE VALVE EXTENSION 1
C10 44650-14 CABLE POWER UC4 BOOM CONTROL JOHN DEERE 1
C12 44658-10 CABLE UC4 VALVE BC JD4920 1
E01 4461BC+ UC4 PLUS BOOM CONTROL PANEL 1
E02 44631 UC4 ULTRASOUND SENSOR 3
E03 45000* UC4 PLUS ROLL SENSOR W TEMPERATURE PROBE VER. 2 1
E04 45001* UC4 PLUS ROLL SENSOR VER. 2 1
H02 44863-23 HOSE ASSEMBLY 122R2-06 32IN L 6FORX 6FORX 2
H06 44862-06 HOSE ASSEMBLY 122R2-04 252 IN L 4FORX 4FORX 1
H20 44865-18 HYDRAULICS FITTING KIT - JD6 1
M01 446BC+MAN7 OPERATOR MANUAL UC4+ SPRAY HEIGHT CONTROL 1
M10 UC4+BC+JD6-INST MANUAL INSTALLATION UC4+ JOHN DEERE 4920 1
M13 104557 GROMMET 7/ 8 ID X 1/ 4 GROOVE WIDTH X 1-1/ 4 GROOVE DIAMETER 1
V01 44963D VALVE BLOCK ASSEMBLY 2 STATION CC/ LS PROP DT 4 BOLT 1
* For systems purchased BEFORE October 1, 2011, the roll sensor part numbers are 44641 and 44642.
