MUTEC MC-8.1 - Manual (Page 5)

CONTENT
INTRODUCTION
Main Differences between MC-8 and MC-8.1 . . . . . . . . . 7
General Function Description . . . . . . . . . . . . . . . . . 7
MC-8 + MC-8.1 Features . . . . . . . . . . . . . . . . . . . . 7
MC-8 + MC-8.1 Applications . . . . . . . . . . . . . . . . . . 7
Peripheral MUTEC Products . . . . . . . . . . . . . . . . . . 8
CONTROL ELEMENTS AND TERMINALS
MC-8 + MC-8.1 Front Panel (both panels are equal) . . . . . . . 9
MC-8 Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . 10
MC-8.1 Rear Panel . . . . . . . . . . . . . . . . . . . . . . . 10
INSTALLATION
Content of the Box . . . . . . . . . . . . . . . . . . . . . . . 11
Placing the device . . . . . . . . . . . . . . . . . . . . . . . 11
Wiring the Word Clock Interfaces . . . . . . . . . . . . . . . 11
Wiring the AES/EBU and AES/EBUid Interfaces . . . . . . . . 12
GENERAL OPERATION
Selecting Function Menus and setting Functions . . . . . . 13
Steps of Operation . . . . . . . . . . . . . . . . . . . . . . . 13
OPERATING THE MC-8 + MC-8.1
MODE and REFERENCE Menus . . . . . . . . . . . . . . . . . 15
General Operation Procedure . . . . . . . . . . . . . . . . . 15
Conversion from one Input to all four Outputs . . . . . . . 16
Conversion from two Inputs to two Output pairs . . . . . . 16
Conversion from four Inputs to four Outputs . . . . . . . . 16
Conversion from one Input to all four Outputs
including the Sampling Rate Conversion Function . . . . . . 17
Conversion from two Inputs to two Output pairs
including the Sampling Rate Conversion Function . . . . . . 17
Conversion from four Inputs to four Outputs
including the Sampling Rate Conversion Function . . . . . . 18
STATUS Menu . . . . . . . . . . . . . . . . . . . . . . . . . 18
REF CLOCK
IN
Menu . . . . . . . . . . . . . . . . . . . . . . . 18
APPENDIX
Pin Assignment of the Connectors . . . . . . . . . . . . . . 19
Switching-off the Termination of the Word Clock Input . . . 20
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . 21
