Technical Data
WORD CLOCK INPUT (WCLK)
Interface
1 x BNC, 200 mV-7 V, unbalanced, input impedance 75 Ω
Lock Range 25.0kHz to 200.0 kHz, 11.2896MHz + 12.288MHz (so-called Super Clocks)
AES/EBU3/11 INPUT
Interface
1 x XLR female, transformer balanced, input impedance 110 Ω, 200 mV – 7.0 V
Format, Resolution AES3 – 1992/2003, AES11 – 1997/2003, 16 – 24 bits
Lock Range 25.0kHz to 200.0kHz
AES/EBU3/11id INPUT (MC-8.1 only)
Interface
1 x BNC, 200 mV-7 V, unbalanced, input impedance 75 Ω
Format, Resolution AES3id – 1995/2001, 16 – 24 bits
Lock Range 25.0kHz to 200.0kHz
WORD CLOCK OUTPUT (WCLK)
Interface 8 x BNC, 3,5 V @ 22 Ω, unbalanced, buffered
Transmitted Clock Rates 25.0kHz to 200.0kHz
AES/EBU3/11 OUTPUT
Interface
1 x XLR male, transformer balanced, 3.5Vpp @ 110Ω, output impedance 110Ω, buffered
Format, Resolution AES3 – 1992/2003, AES11 – 1997/2003, 24 bits
Transmitted Sampling Rates 25.0kHz to 200.0kHz
AES/EBU3/11id OUTPUT (MC-8 only)
Interface
1 x BNC, 1.0 V, unbalanced, output impedance 75 Ω
Format, Resolution AES3id – 1995/2001, 24 bits
Transmitted Clock Rates 25.0kHz to 200.0kHz
INTERNAL REFERENCE CLOCK SPECIFICATIONS
Oscillator type
TCXO, temperature compensated crystal oscillator
Clock accuracy (shipped) < ± 1.0ppm
Clock stability vs. temperature < ± 1.0ppm within -10°C to + 60°C
Operating temperature -10°C to + 60°C
Clock jitter < 10ps (RMS)
POWER SUPPLY
Type
Internal, switching power supply
Input voltage 85V – 264V (automatic adjustment), 47Hz – 440Hz
Power consumption max. 10W
SYSTEM UNIT COVER
Cover size / material / color
196 x 42 x 156mm without connectors (W x H x D), aluminium sheet 1mm, black
Front panel size / material 198 x 44 x 2mm (W x H x D), aluminium
Weight MC-8: ~ 751g, MC-8.1: ~ 748g
