9

„ EVAPORATOR COMPARTMENT (Interior top area)

— All serviceable parts are directly accessible from the

top of the cartridge compartment.
„ COMPRESSOR COMPARTMENT (Bottom rear

area) — Access to compressor compartment requires

removal of the side panel of the cartridge. Condenser

fan access also requires removal of a side panel. Side

panels are secured with 5 Phillips screws. After tubing

and electrical connections are removed, compressor

replacement requires removal of four clips securing

compressor to the base.

„ EVACUATION — Moisture in a refrigeration system

may affect performance.
When large amounts of moisture are present, system

freeze ups will occur. Even in minute amounts, mois-

ture will combine with refrigerants to form an acid.

The corrosive action of this acid forms sludge, which

will plug the lines and drier.
Since most field type vacuum pumps cannot pull a low

enough vacuum to remove all moisture from the sys-

tem, it is recommended that the system be triple evac-

uated, breaking each time with dry refrigerant

nitrogen. Use care to purge air from the charging hose

when breaking the vacuum.

„ CHARGING REFRIGERATION SYSTEM — Refer to

Table 2 for refrigerant type and amount of charge.

Since capillary tube systems have small critical refrig-

erant charges, it is recommended that a field charge

either be weighed in or transferred from a portable

charging cylinder. After maximum vacuum has been

obtained as detailed above, attach charging cylinder to

the system line making sure to purge air from hose

with refrigerant. With the unit running, allow refrig-

erant to run slowly into the system until the desired

charge is reached. When using refrigerant blends it is

recommended to charge into the high side of the sys-

tem with the initial charge and then add any remain-

ing charge into the suction side; however, care must

be taken to meter the remaining amount into the

low side so that excess liquid does not enter the

compressor.
„ TROUBLESHOOTING — Refer to Table 3 and

Figures 10-12.

Before servicing unit, disconnect electrical service.

On sizes 1100L and 1300L, turn disconnect switch

(located on power cord) to the OFF position. Failure

to disconnect electrical service could result in elec-

trical shock and cause personal injury or death.
