0 ripstation quick start guide – MF Digital Ripstation Lite v4.4.11.0 User Manual

Page 15

Ripstation v4.4 Quick Start Guide

100-5-01-000

Ripstation v4.4 – User Manual

Page 15 of 43

3.0 Ripstation Quick Start Guide

Before using the Ripstation software, please use the following steps as a ‘quick start’

guide to set the initial parameters and perform a simple MP3 batch rip.

1. Open the Ripstation software and on the main screen click the Preferences

icon. The dialog box shown in figure 3.0 opens.

Select the ordering of lookups as GD3 First and the multiple FreeDB options Second

then Click OK. You can open a GD3 account by clicking on the following link:

You can add GD3 look ups by clicking on the following link:

Figure 3.0 – Preferences Dialog Box

3. In the main screen click the new batch icon

and the batch properties dialog

opens.

4. If using a 7602/4 device, you will need to configure the side what drive is on, and

choose the correct COM port. To do this from the Source device pull down box,

select 7602/4, the click the edit button beside it:
