UM_6631_077 78M6631 Evaluation Board User Manual
Rev 1 23
3.2 78M6631 Evaluation Board Bill of Materials
Table 13: 78M6631 Evaluation Board Bill of Materials
Item Quantity Reference Part PCB Footprint Manufacturer PN Manufacturer
1 21 C1,C3,C5,C8,C10,C13,C17,
C19,C21,C23,C25,C26,C27,
C28,C29,C31,C33,C35,C36,
C37,C39
0.1µF 0603 GRM188R71H104KA93D Murata Electronics
2 10 C2,C4,C6,C11,C14,C18,C20,
C22,C24,C30
1000pF 0603 C1608X7R2A102K TDK Corporation
3 3 C7,C32,C34 10µF 0805 C2012Y5V1C106Z TDK Corporation
4 1 C9 NC 0603
5 1 C12 100pF 0603 C1608C0G1H101J TDK Corporation
6 1 C15 33pF 0603 C0603C330J5GACTU Kemet
7 1 C16 9pF 0603 C1608C0G1H090C TDK Corporation
8 1 C38 4.7µF 1206P TPSB475K016R1500 AVX Corporation
9 10 J1,J4,J5,J9,J10,J13,J14,
J15,J17,J19
CON4 STERM 8191 Keystone Electronics
10 8 J2,J3,J6,J8,J11,J12,J30, J36 CON4 SIP100P4 PBC36SAAN Sullins Connector Solutions
11 14 TP1,TP2,TP3,J7,J16,J18,
J20,J22,J23,J25,J28,J29,
J31,J35
CON2 SIP100P2 PBC36SAAN Sullins Connector Solutions
12 2 J21,J26 CON3 SIP100P3 PBC36SAAN Sullins Connector Solutions
13 1 J24 CON9 SIP100P9 PBC36SAAN Sullins Connector Solutions
14 1 J27 ICE SIP100P6 PBC36SAAN Sullins Connector Solutions
15 1 J32 SPI DIP100P10 929665-01-36-I 3M
16 1 J33 Weco Tst RAPC712A RAPC712X Switchcraft
17 1 J34 USB-B USBB 154-2442-E Kobiconn
18 1 LED1 LED SIP100P2 4300H1LC Chicago Miniature
19 2 LED2,LED3 LED SIP100P2 4300H7LC Chicago Miniature
20 2 LED4,LED5 LED SIP100P2 606-4300H5LC Chicago Miniature
21 1 LOGO1 Silk WARNING
