FRONT VIEW
PLAN VIEW
— Area must be factory or field insulated
— Area to be field insulated, if ambient conditions require.
NOTE: Waterbox covers are to be insulated by the contractor.
IMPORTANT: 17EX insulation is identical to the 19EX insulation shown
above. 17EX motors do not require insulation.
Fig. 24 — Typical Insulation Area (19EX Shown)
