PS960GLE/ PS965GME Mainboard
24
Time
The time format is: Hour : 00 to 23
Minute : 00 to 59
Second : 00 to 59
To set the date & time, highlight the “Date” & “Time” and use the / or +/- keys to
set the current time.
IDE Channel 0 Master/ Slave
The onboard PCI IDE connectors provide Primary and Secondary channels for connecting up to
four IDE hard disks or other IDE devices.
Each channel can support up to two hard disks; the first is the “Master” and the second is the
“Slave”.
Press to configure the hard disk. The selections include Auto, Manual, and None. Select
“Manual” to define the drive information manually.
You will be asked to enter the following items.
Cylinder: Number of cylinders
Head: Number of read/write heads
Precomp: Write precompensation
Landing Zone: Landing zone
Sector: Number of sectors
The Access Mode selections are as follows:
CHS (HD < 528MB)
LBA (HD > 528MB and supports Logical Block Addressing)
Large (for MS-DOS only)
Auto
